1. Easy to use:
Underneath the inspection door is a door to inspect and clean for
easy maintenance of the interior and interior of the wash.
2. It is necessary to meet the following environmental
requirements:
Functional and reliable combustion burns all the burns but makes it
difficult to remove the dangerous bombardment. Test results from a
variety of different types indicate that gas meets the requirements
of the environment.
3. Irrigation fees can be increased:
The air motor is designed (without limitation) by most units and
can be controlled by a computer. You can add shared tasks. The
plant produces a lot of air pollution (water purification, pumps,
burners, electronic control panels and main vacuum blocks).
4. Installation is complete:
Water, electricity and air can be connected to the site, saving
time and installation work.
5. Reliable tools:
Vodka, check paper, water purifier and vacuum cleaner, support
national pump quality equipment. The support system provides a safe
and reliable climate to achieve and improve air quality.
Technical Parameters
| Main Technical Reference for Fuel (Gas) Steam Generator |
| Item Unit | LSS0.05 | LSS0.1 | LSS0.15 | LSS0J2 |
| Rated evaporation | Kg/h | 50 | 100 | 150 | 200 |
| Rated Pressure PTEPREppoPressure | MPa | 0.4/0.7 |
| Rated steam temperature | c | 151/171 |
| Rated feed water temperature | °C | 20 |
| Evaporator efficiency | / | >92% |
| Applicable Fuel | / | Gas light oil |
| Theoretical fuel consumption | Gas | NM3/h | 4 | 8 | 12 | 16 |
| Light Oil | Kg/h | 3.3 | 6.5 | 9.8 | 13 |
| Gas supply pressure | mbar | 60- 100 |
| water volume | L | <30 |
Note: The fuel consumption in the table is based on the low
calorific value of biomass particles 17084 KJ/Kg (4085
Kcal/Kg).Calculations show that if the low calorific value of
biomass fuel is higher than that, the corresponding fuel
consumption will be more economical than the values in the table.
| Configuration and Interface Size of Fuel (Gas) Steam Generator |
| Item Unit | LSS0.05 | LSSO.l | LSS0.15 | LSS0.2 |
Outward Size of Main Engine
(length * width * height) | / | mm | 620*620*830 | 690*690*968 | 750*750*1130 | 800*800*1286 |
Transport Dimension
| / | mm | 206 | 252 | 303 | 350 |
| Mainframe Transport Weight | DN | mm | G 1/2- | Gl' | Gl" | G 1* |
| Main Steam Valve Pipe Diameter | DN | mm | Gl/2" | Gl/2- | Gl/2- | Gl/2° |
| Feed Water Valve | DN | mm | G1 1/4” | G11/4- | G11/4- | G11/4- |
| Safety Valve Diameter | DN | mm | Gf | GF | Gl" | Gl" |
| Drain Valve Pipe Diameter | DN | mm | 133 | 133 | 159 | 159 |
Remarks: We will reserve rights to change the above mentioned data
due to continuous policy transformation and product improvement.
