1. Compliance with environmental requirements:
High quality and reliable burners allow full combustion of fuel,
while greatly reducing harmful emissions of combustion gases. To
meet the national environmental requirements.
2. Evaporation may increase:
Steam generator can be combined into many units (infinite quantity)
and controlled by computer. The total amount of evaporation can be
increased freely. The relevant components of steam generator
(especially water treatment, pumps, pumps, etc.) The factory
already has water, burner, electrical control box and main valve
device.
3. Facilities are a whole:
The site can be connected to water, electricity and steam, saving
time and installation energy.
4. Reliable accessories:
Supporting burners, control boxes, water treatment, valves, pumps
and other high-quality equipment produced in China. Supporting
equipment ensures the safe operation and improvement of steam
generators. A The total mass of the steam generator.
5. Perfect monitoring system:
The boiler is equipped with an automatic control system and an
improved safety protection device, which provides an automatic
water level control system, a low water level alarm and a stop; an
automatic control device. Steam pressure and high pressure alarm,
steam generator can simply press the start button.
6. Quality service:
Technical consultation, technical services, installation guidance,
regular and irregular user visits, providing quality services at
any time, reassuring users, ensuring procurement.
Technical Parameters
Main Technical Reference for Fuel (Gas) Steam Generator
| Item Unit | LSS0.05 | LSS0.1 | LSS0.15 | LSS0J2 |
| Rated evaporation | Kg/h | 50 | 100 | 150 | 200 |
| Rated Pressure PTEPREppoPressure | MPa | 0.4/0.7 |
| Rated steam temperature | c | 151/171 |
| Rated feed water temperature | °C | 20 |
| Evaporator efficiency | / | >92% |
| Applicable Fuel | / | Gas light oil |
| Theoretical fuel consumption | Gas | NM3/h | 4 | 8 | 12 | 16 |
| Light Oil | Kg/h | 3.3 | 6.5 | 9.8 | 13 |
| Gas supply pressure | mbar | 60- 100 |
| water volume | L | <30 |
Note: The fuel consumption in the table is based on the low
calorific value of biomass particles 17084 KJ/Kg (4085
Kcal/Kg).Calculations show that if the low calorific value of
biomass fuel is higher than that, the corresponding fuel
consumption will be more economical than the values in the table.
Configuration and Interface Size of Fuel (Gas) Steam Generator
| Item Unit | LSS0.05 | LSSO.l | LSS0.15 | LSS0.2 |
Outward Size of Main Engine
(length * width * height) | / | mm | 620*620*830 | 690*690*968 | 750*750*1130 | 800*800*1286 |
Transport Dimension
| / | t | 206 | 252 | 303 | 350 |
| Mainframe Transport Weight | DN | mm | G 1/2- | Gl' | Gl" | G 1* |
| Main Steam Valve Pipe Diameter | DN | mm | Gl/2" | Gl/2- | Gl/2- | Gl/2° |
| Feed Water Valve | DN | mm | G1 1/4” | G11/4- | G11/4- | G11/4- |
| Safety Valve Diameter | DN | mm | Gf | GF | Gl" | Gl" |
| Drain Valve Pipe Diameter | DN | mm | 133 | 133 | 159 | 159 |
Remarks: We will reserve rights to change the above mentioned data
due to continuous policy transformation and product improvement.
