The WDR Series Racks are designed exclusively from the boiler and
storage to help prevent aging and expire. Efficient use of wire and
pipe at home and abroad, average life expectancy is 20,000 hours.
All electrical components are CE and CCC certified to ensure
product integrity and longevity. Oil efficiency in the vessel is
99% calm and clean, and NOx is not released into the atmosphere.
Suitable for environmental requirements.
Product Features
1. A clean switch is easy to install:
Over time, large amounts of garbage disposal will eliminate ash and
slag, prevent friction of friction, reduce fuel quality and ensure
fat stability.
2. High security:
The water computer is controlled by the computer and is transmitted
directly to the computer. It is equipped with waterproof and
pressure protection devices to make it safer.
3. Safety and Long-term:
The first-class professional and advanced high-quality production
technology ensures the quality of each boiler. Average life
expectancy of boilers is 20 years.
4. Good and practical communication:
There is an efficient petrol and expensive dustbag on the board,
and there is a small alarm at the bottom of the pans. Milled gas
meets the earth's ecological needs.
Fifth, the scope of the industry:
Each boiler is designed to meet international standards (ISO)
standards. Each production process uses a number of leading
technologies to ensure product reliability.
6. Best Service:
Technical Services, Installation Instructions, Users may at any
time be able to provide service that can guarantee purchases.
Technical Parameters
| Item | Unit | WDR0.1 | WDR0.2 | WDR0.5 | WDR0.7 | WDR1 | WDR2 | WDR3 |
| Steam Capacity | t/h | 0.1 | 0.2 | 0.5 | 0.7 | 1 | 2 | 3 |
| Working Pressure | MPa | 0.4 | 0.4 | 0.4 | 0.4 | 1.0 | 1.25 | 1.25 |
| Steam Temperature | ℃ | 151 | 151 | 151 | 151 | 184 | 193 | 193 |
| Feed Water Temperature | ℃ | 20 | 20 | 20 | 20 | 20 | 20 | 60 |
| Thermal Efficiency | / | ≥98 |
| Electrical Power | Kw | 72 | 143 | 357 | 501 | 714 | 1429 | 2141
|
Note: If the low calorific value of biomass fuel is larger than
that, the corresponding fuel consumption will be more economical
than that in the table.
Shape and Interface Dimensions of WDR Series Electrical Steam
Boilers
Type Item | WDR0.1 | WDR0.2 | WDR0.5 | WDR0.7 | WDR1 | WDR2 | WDR3 |
Host Transport Dimension | L | mm | 1520 | 1750 | 2700 | 2900 | 3340 | 4300 | 4750 |
| W | mm | 1560 | 1560 | 1700 | 2000 | 2180 | 2180 | 2180 |
| H | mm | 1400 | 1400 | 1600 | 1850 | 2015 | 2015 | 2015 |
| Main Steam Valve Pipe Diameter | DN | mm | 25 | 25 | 25 | 40 | 65 | 80 | 80 |
| Feed Water Valve | DN | mm | 25 | 25 | 25 | 40 | 40 | 40 | 40 |
| Safety Valve Diameter | DN | mm | 40 | 40 | 40 | 50 | 2*40 | 2*50 | 2*50 |
| Drain Valve Pipe Diameter | DN | mm | 40 | 40 | 40 | 40 | 40 | 40 | 40 |
Remarks: We will reserve rights to change the above mentioned data
due to continuous policy transformation and product improvement.
