Product Discription

SZS Series Double Drum Oil and Gas Fired Steam Boiler

The dual SZS boiler temperature and dual steam boiler are double drum, D-vertical arrangement, high speed boiler. Various boilers include upper and lower boiler drums, diaphragm walls, rim tubes and capacitors. Fuel is burned in the boiler, and flue gas is released from the convection pipe to the chimney and heat extraction device. With mechatronic structure, performance is at the forefront of China.

Product Features

1. Suitable for all fuels:

Large furnace area and fuel completely burned. It is ideal for low calorie fuels such as gas cookers and blast furnaces. High calorie fuels burn better, such as natural gas, liquid gas, and so on.

2. With load capacity:

The heating area is large, the furnace area is large, the output is large, and the storage capacity is reliable.

3. Reasonable structure:

The front water wall is installed in front of the boiler to facilitate the placement of the burner head to ensure water level and cooling near the burner, which helps eliminate carbon savings from burners and burn more fuel.

4. Easy to maintain:

The boiler wall is equipped with an explosive door, fire-resistant hole and inspection door. Pipe boiler heating is provided with transparent opening before and after to facilitate boiler maintenance.

5. Reduce heat loss:

The use of thick insulation reduces heat loss from the boiler and improves heat efficiency.

6. Long service life:

Excellent professional design, advanced production technology, rigorous inspection and quality control ensure the quality of all boilers. The conventional boiler service life is over 20 years.

Techinical Parameters

Main Parameters of SZS Series Oil & Gas Fired Steam Boiler

Remarks: The fuel consumption in above table are counted the low calorific value of light oil as 42915 KJ/Kg(10260Kcal/Kg), the low calorific value of natural gas as 35588 KJ/NM3(8500Kcal/NM3), the low calorific value of liquefied oil as 45998 KJ/Kg(11000Kcal/Kg), the low calorific value of city gas as 16750 KJ/NM3(4000Kcal/NM3).

External and Interface Dimension of SZS Series Oil & Gas Fired Steam Boiler

Remarks: We will reserve rights to change the above mentioned data due to continuous policy transformation and product improvement.

     It is one of the ten most famous towns in Zhongzhou, which is adjacent to National Highway 107 in the South and Beijing-Guangzhou Railway in the north. The company has the B-class boiler manufacturing license issued by the General Administration of Inspection and Quarantine of the State Quality Supervision Bureau and the D1 and D2-class pressure vessel manufacturing license. It is a comprehensive manufacturer of steam boilers, hot water boilers, heat carrier boilers, pressure vessels of Class I and II and auxiliary machines for various boilers. The company was founded in 1987.

     After relocation and expansion, it now has perfect production equipment and testing means, a high-quality staff and technical team, and has established and improved a set of quality assurance system. The quality policy of "quality-oriented, safety first, energy-saving, environmental protection, refinement" and "the pass rate of main parts inspection is over 95%, the pass rate of welding seam inspection is over 98%, the pass rate of product inspection is 100%, the pass rate of products manufactured is 100%, and the implementation rate of regulations and standards is 100%" have been formulated.

Product quality is safe and reliable, environmental protection and energy saving, and conforms to the national standards and industry standards. Pressure vessel products are inspected by the quality and technical supervision department and issued with product inspection certificate.
