1. in line with environmental protection:
high quality and reliable burner, so that fuel can be fully burned,
while greatly reducing harmful emissions in flue gas. The test
results of relevant departments show that the fuel (gas) steam
generator meets the national environmental protection requirements.
2. The amount of evaporation can be increased:
Steam generators can be modularized into several units (unlimited
number) and controlled by computer.Total evaporation can be added
freely.The relevant components of steam generator (including water
treatment, water pump, burner, electronic control box and main
valve instruments) are already in the factory.
3. Installation is an integral whole:
It can be connected with water, electricity and steam pipes on
site, which saves time and effort in installation.
4. Reliable accessories:
matching burners, control boxes, water treatment, and valves, pumps
are made of domestic high-quality equipment. The matching equipment
can ensure the safe and reliable operation of the steam generator
and improve the overall quality of the steam generator.
5. excellent control system:
the boiler is equipped with perfect automatic control device and
safety protection device to realize automatic water level control
System and low water level alarm, stoppage; steam pressure
automatic control and overpressure alarm; boiler automatic
ignition, burner self-fire Dynamic regulation and flameout
protection ensure the safe operation of the boiler. Users only need
to press the start button lightly, the steam generator can press
it.
6. Quality Services:
Technical Consulting, Technical Services, Installation Guidance,
Regular and Irregular Visits to Users,Provide high-quality and
perfect services at any time, so that users can buy at ease, with
comfort
Technical Parameters
Main Technical Reference for Fuel (Gas) Steam Generator
| Item Unit | LSS0.05 | LSS0.1 | LSS0.15 | LSS0J2 |
| Rated evaporation | Kg/h | 50 | 100 | 150 | 200 |
| Rated Pressure PTEPREppoPressure | MPa | 0.4/0.7 |
| Rated steam temperature | c | 151/171 |
| Rated feed water temperature | °C | 20 |
| Evaporator efficiency | / | >92% |
| Applicable Fuel | / | Gas light oil |
| Theoretical fuel consumption | Gas | NM3/h | 4 | 8 | 12 | 16 |
| Light Oil | Kg/h | 3.3 | 6.5 | 9.8 | 13 |
| Gas supply pressure | mbar | 60- 100 |
| water volume | L | <30 |
Note: The fuel consumption in the table is based on the low
calorific value of biomass particles 17084 KJ/Kg (4085
Kcal/Kg).Calculations show that if the low calorific value of
biomass fuel is higher than that, the corresponding fuel
consumption will be more economical than the values in the table.
Configuration and Interface Size of Fuel (Gas) Steam Generator
| Item Unit | LSS0.05 | LSSO.l | LSS0.15 | LSS0.2 |
Outward Size of Main Engine
(length * width * height) | / | mm | 620*620*830 | 690*690*968 | 750*750*1130 | 800*800*1286 |
Transport Dimension
| / | t | 206 | 252 | 303 | 350 |
| Mainframe Transport Weight | DN | mm | G 1/2- | Gl' | Gl" | G 1* |
| Main Steam Valve Pipe Diameter | DN | mm | Gl/2" | Gl/2- | Gl/2- | Gl/2° |
| Feed Water Valve | DN | mm | G1 1/4” | G11/4- | G11/4- | G11/4- |
| Safety Valve Diameter | DN | mm | Gf | GF | Gl" | Gl" |
| Drain Valve Pipe Diameter | DN | mm | 133 | 133 | 159 | 159 |
Remarks: We will reserve rights to change the above mentioned data
due to continuous policy transformation and product improvement.
